I am attempting to synchronize the date and time for a number of computers belonging to a non-domain, statically configured network (e.g. computer B in illustration) with a node which is residing in a domain on a different network interface (A).

Despite my efforts, I am unable to make synchronization happen :-(

Network topology

A:   10.0.0.A / 172.64.0.A   Windows 2008 Server (32bit)
B:   10.0.0.B                Windows 7

So far, I have tried to enable the NTP Server on A through different variations on this idea:

C:\> w32tm /config /reliable:yes
C:\> w32tm /config /update
C:\> net stop w32time
HKLM\SYSTEM\CurrentControlSet\Services\W32Time\Config -> AnnounceFlags = 0x5 (or 0xA)
HKLM\SYSTEM\CurrentControlSet\Services\W32Time\TimeProviders\NTPServer -> Enabled = 1
C:\> net start w32time

On B, I have tried variations on the following:

C:\> w32tm /config /syncfromflags:manual /manualpeerlist:10.0.0.A
The command completed successfully.
C:\> w32tm /config /update
The command completed successfully.
C:\> net stop w32time
C:\> net start w32time
C:\> w32tm /resync
Sending resync command to local computer
The computer did not resync because no time data was available.

I have also attempted to make do the configurations on A and B through local group policy on the machines in question, with no result.

(edit) Restrictions: The two networks are completely separate, except for A and a few workstations connected to both. Otherwise, the static network on the right is completely isolated from the world (it is a thin client network). Any topology changes are unfortunately out of the question at this point.

I am willing to look at possible workarounds, and on-the-second accuracy is not a major concern to me (+-30 seconds is ok). I'd very much prefer to avoid 3rd party software. One workaround I have attempted is to have a logon Powershell script on B read the time on A, but that has its own problems, possibly for another thread.

tor
  • 171
  • 9

1 Answers1

1

If server A isn't a DC, don't mess with trying to make it an NTP server...you'll only confuse it and the domain's other workstations.

Instead, point B at the PDC emulator on the domain in the left of the picture.

Make sure the network is allowing NTP traffic between the two networks as well.

If for some reason B can't get to a DC in the domain on the left (routing rules, IT restrictions, whatever), then find out which external NTP server the PDC emulator on the domain is syncing with and have B sync with that external NTP server.

TheCleaner
  • 32,627
  • 26
  • 132
  • 191
  • Thank you for great suggestions! Unfortunately, neither solution is possible; B does not have communication with the PDC emulator, or any DC for that matter. The two networks are completely separate, except for A and a few workstations connected to both. Otherwise, the static network on the right is completely isolated from the world (it is a thin client network). Any topology changes are unfortunately out of the question at this point :( – tor May 09 '14 at 13:27
  • Yeah, that's why I left the last paragraph in there, which is a good viable option. – TheCleaner May 12 '14 at 00:51
