EDIT 11.07.2020
I prepared a custom vhd via virtualbox. It has the same bluescreen, but now I'm getting into cmd. mdsched worked fine -> So no memory issue...
Informations:
- HP Proliant 380 G9
- QEMU emulator version 2.12.0 (qemu-kvm-2.12.0-99.module_el8.2.0+385+c644c6e8.2)
- libvirt version: 4.5.0, package: 42.module_el8.2.0+320+13f867d7
Maschine-Config of Virtmanager
<domain type="kvm">
<name>srvvmdc</name>
<uuid>cadd396c-c953-454b-9a1b-445eb50037fe</uuid>
<metadata>
<libosinfo:libosinfo xmlns:libosinfo="http://libosinfo.org/xmlns/libvirt/domain/1.0">
<libosinfo:os id="http://microsoft.com/win/2k16"/>
</libosinfo:libosinfo>
</metadata>
<memory unit="KiB">8388608</memory>
<currentMemory unit="KiB">8388608</currentMemory>
<vcpu placement="static">6</vcpu>
<os>
<type arch="x86_64" machine="pc-q35-rhel7.6.0">hvm</type>
</os>
<features>
<acpi/>
<apic/>
<hyperv>
<relaxed state="on"/>
<vapic state="on"/>
<spinlocks state="on" retries="8191"/>
</hyperv>
<vmport state="off"/>
</features>
<cpu mode="host-model" check="partial">
<model fallback="allow"/>
</cpu>
<clock offset="localtime">
<timer name="rtc" tickpolicy="catchup"/>
<timer name="pit" tickpolicy="delay"/>
<timer name="hpet" present="no"/>
<timer name="hypervclock" present="yes"/>
</clock>
<on_poweroff>destroy</on_poweroff>
<on_reboot>restart</on_reboot>
<on_crash>destroy</on_crash>
<pm>
<suspend-to-mem enabled="no"/>
<suspend-to-disk enabled="no"/>
</pm>
<devices>
<emulator>/usr/libexec/qemu-kvm</emulator>
<disk type="file" device="disk">
<driver name="qemu" type="qcow2"/>
<source file="/home/administrator/VM/srvvmdc.qcow2"/>
<target dev="sda" bus="sata"/>
<address type="drive" controller="0" bus="0" target="0" unit="0"/>
</disk>
<disk type="file" device="cdrom">
<driver name="qemu" type="raw"/>
<source file="/home/administrator/Downloads/17763.737.190906-2324.rs5_release_svc_refresh_SERVERESSENTIALS_OEM_x64FRE_de-de_1.iso"/>
<target dev="sdb" bus="sata"/>
<readonly/>
<boot order="1"/>
<address type="drive" controller="0" bus="0" target="0" unit="1"/>
</disk>
<disk type="file" device="cdrom">
<driver name="qemu" type="raw"/>
<source file="/home/administrator/Downloads/virtio-win-0.1.171.iso"/>
<target dev="sdc" bus="sata"/>
<readonly/>
<address type="drive" controller="0" bus="0" target="0" unit="2"/>
</disk>
<controller type="usb" index="0" model="qemu-xhci" ports="15">
<address type="pci" domain="0x0000" bus="0x02" slot="0x00" function="0x0"/>
</controller>
<controller type="sata" index="0">
<address type="pci" domain="0x0000" bus="0x00" slot="0x1f" function="0x2"/>
</controller>
<controller type="pci" index="0" model="pcie-root"/>
<controller type="pci" index="1" model="pcie-root-port">
<model name="pcie-root-port"/>
<target chassis="1" port="0x10"/>
<address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x0" multifunction="on"/>
</controller>
<controller type="pci" index="2" model="pcie-root-port">
<model name="pcie-root-port"/>
<target chassis="2" port="0x11"/>
<address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x1"/>
</controller>
<controller type="pci" index="3" model="pcie-root-port">
<model name="pcie-root-port"/>
<target chassis="3" port="0x12"/>
<address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x2"/>
</controller>
<controller type="pci" index="4" model="pcie-root-port">
<model name="pcie-root-port"/>
<target chassis="4" port="0x13"/>
<address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x3"/>
</controller>
<controller type="pci" index="5" model="pcie-root-port">
<model name="pcie-root-port"/>
<target chassis="5" port="0x14"/>
<address type="pci" domain="0x0000" bus="0x00" slot="0x02" function="0x4"/>
</controller>
<controller type="virtio-serial" index="0">
<address type="pci" domain="0x0000" bus="0x03" slot="0x00" function="0x0"/>
</controller>
<interface type="bridge">
<mac address="52:54:00:68:cb:7c"/>
<source bridge="bridge0"/>
<model type="e1000e"/>
<address type="pci" domain="0x0000" bus="0x01" slot="0x00" function="0x0"/>
</interface>
<serial type="pty">
<target type="isa-serial" port="0">
<model name="isa-serial"/>
</target>
</serial>
<console type="pty">
<target type="serial" port="0"/>
</console>
<channel type="spicevmc">
<target type="virtio" name="com.redhat.spice.0"/>
<address type="virtio-serial" controller="0" bus="0" port="1"/>
</channel>
<input type="tablet" bus="usb">
<address type="usb" bus="0" port="1"/>
</input>
<input type="mouse" bus="ps2"/>
<input type="keyboard" bus="ps2"/>
<graphics type="spice" autoport="yes">
<listen type="address"/>
<image compression="off"/>
</graphics>
<sound model="ich9">
<address type="pci" domain="0x0000" bus="0x00" slot="0x1b" function="0x0"/>
</sound>
<video>
<model type="qxl" ram="65536" vram="65536" vgamem="16384" heads="1" primary="yes"/>
<address type="pci" domain="0x0000" bus="0x00" slot="0x01" function="0x0"/>
</video>
<redirdev bus="usb" type="spicevmc">
<address type="usb" bus="0" port="2"/>
</redirdev>
<redirdev bus="usb" type="spicevmc">
<address type="usb" bus="0" port="3"/>
</redirdev>
<memballoon model="virtio">
<address type="pci" domain="0x0000" bus="0x04" slot="0x00" function="0x0"/>
</memballoon>
</devices>
</domain>
The installation process works well:
But after installation and reboot:
Whats that?
EDIT 03.07.2020
Windows 10 Pro VM & Centos 8 VM working well... Hardware was tested 2 days ago.
EDIT 03.07.2020
Log from the vm of qemu
2020-07-03 18:28:51.099+0000: starting up libvirt version: 4.5.0, package: 42.module_el8.2.0+320+13f867d7 (CentOS Buildsys bugs@centos.org, 2020-05-28-17:13:31, ), qemu version: 2.12.0qemu-kvm-2.12.0-99.module_el8.2.0+385+c644c6e8.2, kernel: 4.18.0-193.6.3.el8_2.x86_64, hostname: hypervisor.wulf.systems LC_ALL=C PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin QEMU_AUDIO_DRV=spice /usr/libexec/qemu-kvm -name guest=srvvmdc,debug-threads=on -S -object secret,id=masterKey0,format=raw,file=/var/lib/libvirt/qemu/domain-5-srvvmdc/master-key.aes -machine pc-q35-rhel7.6.0,accel=kvm,usb=off,vmport=off,dump-guest-core=off -cpu Haswell-noTSX-IBRS,vme=on,ss=on,vmx=on,f16c=on,rdrand=on,hypervisor=on,arat=on,tsc-adjust=on,umip=on,md-clear=on,stibp=on,arch-capabilities=on,ssbd=on,xsaveopt=on,pdpe1gb=on,abm=on,ibpb=on,skip-l1dfl-vmentry=on,hv-time,hv-relaxed,hv-vapic,hv-spinlocks=0x1fff -m 8192 -realtime mlock=off -smp 6,sockets=6,cores=1,threads=1 -uuid cadd396c-c953-454b-9a1b-445eb50037fe -no-user-config -nodefaults -chardev socket,id=charmonitor,fd=31,server,nowait -mon chardev=charmonitor,id=monitor,mode=control -rtc base=localtime,driftfix=slew -global kvm-pit.lost_tick_policy=delay -no-hpet -no-shutdown -global ICH9-LPC.disable_s3=1 -global ICH9-LPC.disable_s4=1 -boot strict=on -device pcie-root-port,port=0x10,chassis=1,id=pci.1,bus=pcie.0,multifunction=on,addr=0x2 -device pcie-root-port,port=0x11,chassis=2,id=pci.2,bus=pcie.0,addr=0x2.0x1 -device pcie-root-port,port=0x12,chassis=3,id=pci.3,bus=pcie.0,addr=0x2.0x2 -device pcie-root-port,port=0x13,chassis=4,id=pci.4,bus=pcie.0,addr=0x2.0x3 -device pcie-root-port,port=0x14,chassis=5,id=pci.5,bus=pcie.0,addr=0x2.0x4 -device pcie-root-port,port=0x15,chassis=6,id=pci.6,bus=pcie.0,addr=0x2.0x5 -device qemu-xhci,p2=15,p3=15,id=usb,bus=pci.2,addr=0x0 -device virtio-scsi-pci,id=scsi0,bus=pci.5,addr=0x0 -device virtio-serial-pci,id=virtio-serial0,bus=pci.3,addr=0x0 -drive 'file=/home/administrator/Downloads/17763.737.190906-2324.rs5_release_svc_refresh_SERVERESSENTIALS_OEM_x64FRE_de-de_1(1).iso,format=raw,if=none,id=drive-sata0-0-1,media=cdrom,readonly=on' -device ide-cd,bus=ide.1,drive=drive-sata0-0-1,id=sata0-0-1,bootindex=1 -drive file=/home/administrator/Downloads/virtio-win-0.1.171.iso,format=raw,if=none,id=drive-sata0-0-2,media=cdrom,readonly=on -device ide-cd,bus=ide.2,drive=drive-sata0-0-2,id=sata0-0-2 -drive file=/home/administrator/VM/srvvmdc.qcow2,format=qcow2,if=none,id=drive-scsi0-0-0-3 -device scsi-hd,bus=scsi0.0,channel=0,scsi-id=0,lun=3,drive=drive-scsi0-0-0-3,id=scsi0-0-0-3 -netdev tap,fd=33,id=hostnet0 -device e1000e,netdev=hostnet0,id=net0,mac=52:54:00:68:cb:7c,bus=pci.1,addr=0x0 -chardev pty,id=charserial0 -device isa-serial,chardev=charserial0,id=serial0 -chardev spicevmc,id=charchannel0,name=vdagent -device virtserialport,bus=virtio-serial0.0,nr=1,chardev=charchannel0,id=channel0,name=com.redhat.spice.0 -spice port=5902,addr=127.0.0.1,disable-ticketing,image-compression=off,seamless-migration=on -device qxl-vga,id=video0,ram_size=67108864,vram_size=67108864,vram64_size_mb=0,vgamem_mb=16,max_outputs=1,bus=pcie.0,addr=0x1 -device ich9-intel-hda,id=sound0,bus=pcie.0,addr=0x1b -device hda-duplex,id=sound0-codec0,bus=sound0.0,cad=0 -chardev spicevmc,id=charredir0,name=usbredir -device usb-redir,chardev=charredir0,id=redir0,bus=usb.0,port=2 -chardev spicevmc,id=charredir1,name=usbredir -device usb-redir,chardev=charredir1,id=redir1,bus=usb.0,port=3 -device virtio-balloon-pci,id=balloon0,bus=pci.4,addr=0x0 -sandbox on,obsolete=deny,elevateprivileges=deny,spawn=deny,resourcecontrol=deny -msg timestamp=on 2020-07-03T18:28:51.185055Z qemu-kvm: -chardev pty,id=charserial0: char device redirected to /dev/pts/3 (label charserial0)
EDIT 04.07.2020 I just downloaded the .vhd from microsoft and converted into .qcow2 and it works well...
EDIT 06.07.2020 Here is the debug log of libvirt - but I can't see any error (one there is one, but I think thats not the error...). The machine is "srvvmdc". Dropbox Link to get the log
