How to view certificate chain using openssl

Question

I use a mixture of Windows, Linux, and Macs and have noticed big differences in how each OS shows certificate details using the default tools available in each.

The way Windows displays certificate details is very succinct. Specifically, the certificate chain. See screenshot as an example. And here it is again in Windows, but using the certutil tool. (okay it's inspecting a pfx but you get the point). However on a Mac, this is how it shows the same cert in Keychain Access. As you can see, it doesn't have a nice hierarchical view that makes it easy to identify the certificate chain that Windows or certutil shows - at least not to my (possibly) untrained eyes. I also haven't figured out a way to show the certificate chain using openssl either, for example, the following command openssl x509 -in certificate.crt -text does not show a hierarchical chain - only the issuer. So is there a way to view a certificate's chain whether it be text or an image using openssl or native Mac tools?

[Edit]: I often create PFX files with the entire certificate chain (bar the root) for distribution within the company I work for. As part of the process I double check that the certs I've downloaded from the issuing CA are correct and that they're in the right order before passing it to openssl to mint the PFX. So to be clear, I'm questioning how to view the chain of a certificate I am working on locally on my computer.

Answer 1

Use showcerts:

openssl s_client -showcerts -connect www.serverfault.com:443

Output with some information removed for brevity:

depth=2 O = Digital Signature Trust Co., CN = DST Root CA X3
verify return:1
depth=1 C = US, O = Let's Encrypt, CN = Let's Encrypt Authority X3
verify return:1
depth=0 CN = *.stackexchange.com
verify return:1
---
Certificate chain
 0 s:/CN=*.stackexchange.com
   i:/C=US/O=Let's Encrypt/CN=Let's Encrypt Authority X3
-----BEGIN CERTIFICATE-----
*REMOVED*
-----END CERTIFICATE-----
 1 s:/C=US/O=Let's Encrypt/CN=Let's Encrypt Authority X3
   i:/O=Digital Signature Trust Co./CN=DST Root CA X3
-----BEGIN CERTIFICATE-----
*REMOVED*
-----END CERTIFICATE-----
---
Server certificate
subject=/CN=*.stackexchange.com
issuer=/C=US/O=Let's Encrypt/CN=Let's Encrypt Authority X3
---
No client certificate CA names sent
Peer signing digest: SHA512
Server Temp Key: X25519, 253 bits

Answer 2

From a certificate bundle, you can use crl2pkcs7 that is not limited to a CRL:

openssl crl2pkcs7 -nocrl -certfile server_bundle.pem | openssl pkcs7 -print_certs -noout

From a live server, we need an additional stage to get the list:

echo | openssl s_client -connect host:port [-servername host] -showcerts | openssl crl2pkcs7 -nocrl | openssl pkcs7 -noout -print_certs

Use the -servername parameter in case your host serves multiple domains to get the right certificate.

Answer 3

Just building upon Dave Thompson's answer, this is what you need to verify a certificate bundle/chain consisting of a intermediate and your own leaf:

# split your certificate chain into individual certificates
$ csplit -z -f individual- bundle.pem '/-----BEGIN CERTIFICATE-----/' '{*}'
1977
1850

# verify the chain and show the info in the chain
$ openssl verify -show_chain -untrusted individual-01 individual-00
individual-00: OK
Chain:
depth=0: CN = foobar.example.com (untrusted)
depth=1: C = NO, O = Buypass AS-983163327, CN = Buypass Class 2 CA 2 (untrusted)
depth=2: C = NO, O = Buypass AS-983163327, CN = Buypass Class 2 Root CA

Answer 4

I can't help for other Mac tools including native. OpenSSL is a pure commandline product with no GUI, although of course you could use the library part (libcrypto) and write your own GUI.

From commandline, openssl verify will if possible build (and validate) a chain from the/each leaf cert you give it, plus intermediate(s) from -untrusted (which can be repeated), and possibly more intermediate(s) to a root (or anchor) in -trusted or -CAfile and/or -CApath or the default truststore, which is usually determined by your system or build but can be overridden with envvars. If this fails it gives an error. In 1.1.0 up if it succeeds and you also specify -show_chain, it displays the subject names of each cert -- which may or may not be enough to identify them. If you only have one cert per subject, that's fairly easy. If you have certs for the same subject from different issuers, looking at the next cert's name (except on the last, which is selfsigned unless you also use -partial_chain) is enough. If you have multiple certs for the same subject and issuer it's harder.

I often create PFX files with the entire certificate chain (bar the root) for distribution within the company I work for. As part of the process I double check that the certs I've downloaded from the issuing CA are correct and that they're in the right order before passing it to openssl to mint the PFX.

Except for the 'bar the root' part, you could reverse this workflow. Instead of manually building and checking the chain and then using it, you could use openssl pkcs12 -export -chain and provide the possible chain certs as (or in) -CAfile and/or -CApath. That would build the chain (actually validating it also as a side-effect) and create a PKCS12 containing only the privatekey and leaf plus valid chain if successful, but give an error and create no output if unsuccessful -- i.e. if you don't have a valid chain.

Answer 5

I know I am late. But I was looking for a solution for the same problem. After googling for 20 mins, figured out.

if the certificate chain is saved as Base64:

openssl pkcs7 -in certificate_chain.p7b -noout -text -print_certs

if the certificate chain is saved as DER:

openssl pkcs7 -inform DER -in certificate_chain.p7b -noout -text -print_certs

Answer 6

Connect to server, obtain certificate and output in text format:

echo -n | openssl s_client -connect example.com:443 2> /dev/null | openssl x509 -text

echo -n will prevent openssl hanging.
